Laboratory Instruments

Product Details:

Bio Safety Cabinet:

• With sincerity and hard work of our professionals, we have carved a niche for ourselves in this domain by offering Bio Safety Cabinet. At our production unit, this cabinet is manufactured using optimum quality components and latest techniques under the strict guidance of dexterous engineers. To eliminate any kind of defect, this cabinet is examined against several measures of quality by our quality examiners in synchronization with defined industry standards.

Features:

• High performance
• Anti-corrosive body
• Easy usage

Technical Specifications for Bio Safety Cabinet:

• Main body should be mad in mild steel (Heavy gauge- 19 G)
• Table top and working zone should be made of stainless steel [(304 grade)- Heavy gauge- 20G
• Table top should be in two parts:
• Front perforated portion 5” in size
• Non perforated working zone
• Work Area should be approximately 900 x 600 x 600 mm (3 – 2 feet) in size with shutter opening of 489 mm
• Overall Size of the cabinet should be approximately 1100 x 825 x 2450 mm
• Air Flow should be vertical down flow with 70 % Surqulation 30 % exhaust
• Cleanliness level should be less than 3.5 particles/ litre of 0.5 μm and larger
• Noise Level should be less than 65 db
• Vibration level: Less than 2.3 μm
• Average air flow should be 90±20 fpm (down flow)



Standard Accessories:

• HEPA filters should be MINIPLEAT with 99.99% efficiency for 0.3 micron with integral metal guards & filter frame gaskets and manufactured in class 1000 super clean air conditioned environment for longer life.
• Air pressurization system should be statically and dynamically balanced, fitted with special vibration reducing system to suit low noise and vibrations.
• Front door should be made of acrelik (4mm), adjustable as per lab requirement, vertical sliding fully aotometic
• UV lamp should be in working zone (40 micro watts/ square cm at 254 nm or better) and placed so that the operator cannot see directly i.e. eyes should be always protected.
• Should have Rehabitable pre filters should have efficiency of more than 80%.
• Should have Switches & Electrical sockets outlets for 15/5 amp.
• Should have Pressure Monitors like Magnehelic gauge are required to indicate pressure drop acr
• Exhaust blower should be capable for 100% exhaust interconnected with supply air blower; system should only start when the negative pressure is develop
• Back holes should be there on vertical walls to provide more work area on table
• Should have Switches & Electrical sockets outlets for 16 amp.
• Suitable power supply 230 volt a/c

Additional Information:

• Item Code: Airflow
• Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P
• Port of Dispatch: Mumbai
• Production Capacity: 50
• Delivery Time: 1-2 weeks
• Packaging Details: Wooden Box

Product Details:

Vertical Laminar Airflow Cabinet :
Our Athena GMP model, Laminar Air Flow Chambers are available in Vertical as well as Horizontal Models and used where high-tech manufacturing and assembly takes place and thus widely found in semiconductor assembly, biotechnology, pharmaceutical, aerospace, food, medical devices and hospitals. These Laminar air flow chambers are tested on various quality parameters to ensure smooth functioning and manufactured with Class 100 airflow in the work region in accordance to US FED STD 209.

Specification:

• Air Velocity: Between 0.4 to 0.5 m/s with /- 20%
• HEPA Efficiency; 99.997 % at 0.3 microns with DOP test
• Pre filter Washable with a stoppage: up to 90 % at 5 microns
• Sound Level: Less than 65 dB (A)
• Light Intensity (Lux) :900 - 1300 Lux
• Cleanliness: US Federal Standard 209 E
• Class 100



Available standard sizes:

HM: Horizontal Model/VM: Vertical Model.



Additional Information:

• Item Code: laminar
• Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P
• Port of Dispatch: Mumbai
• Production Capacity: 50
• Delivery Time: 2 weeks
• Packaging Details: Wooden Box

Product Details:

Vertical Laminar Airflow Cabinet :

• Our vertical laminar air flow has vertical direction flow and particle retention above 0.5 micron. These are appreciated for their low noise and versatile usage. These have been designed with latest technology and can also be designed as per the specifications, provided by our clients.

Application:

• The vertical laminar air flow cabinets is designed to provide a high degree of protection for process products In laboratories and production facilities. Many critical applications in the medical, pharmaceutical, nuclear-power, and micro electronic fields demand an ultra-clean work environment which is free from biological and particulate contamination.

Operation:

• Ambient Air is draw in through pre-filter and is introduced in the work zone through the HEPA filter. The average velocity in the work zone is maintained between 0.4 and 0.5 m/s. Air cleanliness in the work zone is better than class 3.5 (100) in accordance with US FED STD 209 E

Construction:

• The cabinets are fabricated out of thick board duly sunmica clad or mild steel cabinet duly epoxy coated. The work table is made of thick board which is sunmica clad at top or S. S Table top will be provided as optional accessories. All joints are sealed with silastic sealant. Side panels are provided of thick transparent acrylic sheets. The unit is fitted with pre-filter and is made to pass through highly effective HEPA (High Efficiency Particular Air) filter having efficiency rating as high as 99.997% with hot, DOP, thus retaining all air-borne particles of size : 0.3 micron and larger. Using a dynamic machine, the blower and motor assembly is statically and dynamically balanced. Blowers are mounted on vibration isolation mounts to minimize vibration. The working is illuminated by fluorescent lightings fitted to the unit. Height of the working table provides comfortable “ Sit Down” working position for the operation to work on 220/230 volts AC. supply. A Laminar Flow is designed to provide working space comprising as standard features HEPA filter having efficiency of 99.97% down to 0.3% microns,prefilter 90% down to 5 microns, suitable motor blowing assemblies, working table topside Acrylic panel, fluorescent tube light & pressure differential Manometer. Inside shelf made of S.S.

Specifications:

Additional Information:

• Item Code: LaminarAirFlow
• Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P,D/A
• Port of Dispatch: Mumbai
• Production Capacity: 10
• Delivery Time: 1-2 weeks
• Packaging Details: Wooden Box
